The picoPSU-80 plugs directly into a motherboard ATX connector and measures just 31x45x13mm - about the size of two AA batteries. The picoPSU-80 generates up to 80 Watts of power from a 12V DC supply connected by a 2.5mm/5.5mm Jack, at over 96% efficiency. An attached cable harness provides:

• 20pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power

Compatibility: The picoPSU-80 can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you. Compatible Universal AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter

Adding more SATA drives: The picoPSU-80 has one SATA connector and a Molex connector. To power more SATA drives use a Molex to SATA or 2x SATA cable.

P4 Power Connectors: If your board has a 4-pin 12V P4 power connector, you will need to use the 12V P4 Extension Cable for picoPSU-80, or a Molex to 12V P4 Power Cable, or use the picoPSU-90.

Long Life: The picoPSU-80 is marked for long life production and is guaranteed to have a life cycle of 5 years or more.

Notes: Not suitable for use with batteries, unstable power sources or voltages other than 12V.

Installation Guide

The picoPSU-90 plugs directly into a motherboard ATX connector and measures just 31x45x13mm - about the size of two AA batteries. The picoPSU-90 generates up to 90 Watts of power from a 12V DC supply connected by a 2.5mm/5.5mm Jack, at over 96% efficiency. An attached cable harness provides:

• 20pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• 12V P4 Power

Compatibility: The picoPSU-90 can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you. Compatible Universal AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter

Adding more SATA drives: The picoPSU-90 has one SATA connector and a Molex connector. To power more SATA drives use a Molex to SATA or 2x SATA cable.

P4 Power Connectors: The picoPSU-90 comes with a 4-pin P4 Connector on the cable harness so is ready to use with boards with P4 sockets such as the Asus E35M1-I Deluxe, Gigabyte GA-D525TUD, E350N-USB3, Intel D945GCLF, D945GCLF2, D425KT, D525MW, Sapphire Pure Fusion Mini E350 and several others (check board listings).

Cable Lengths: (1) DC Input cable is 25cm long (2) 12V P4 Cable is 23cm long (3) Molex HDD Connector is 20cm along cable; SATA connector is additional 10cm. Measurements do not include connectors.

Notes: Not suitable for use with batteries, unstable power sources or voltages other than 12V.

Installation Guide

The picoPSU-120 plugs directly into a motherboard ATX connector and measures just 31x45x20mm - about the size of two AA batteries. The picoPSU-120 generates up to 120 Watts of power from a 12V DC supply, at over 96% efficiency. An attached cable harness provides:

• 20pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• Molex Floppy Power

Compatibility: The picoPSU-120 can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. Additionally most lower power consumption Mini-ITX boards with Intel and AMD processors up to around 65W TDP can be powered. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you. Compatible Universal AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter
• 150W AC Adapter 4-pin*
• 192W AC Adapter 4-pin*

*The 2.5/5.5mm Jack can be replaced with the more robust 4-pin Mini-DIN connector that is supplied with our 150W and 192W AC Adapters.

Adding more SATA drives: The picoPSU-120 has one SATA connector and a Molex connector. To power more SATA drives use a Molex to SATA or 2x SATA cable.

P4 Power Connectors: If your board has a 4-pin 12V P4 power connector, you will need to use a Molex to 12V P4 Power Cable, or a picoPSU-90 or 150/160-XT.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you.

Long Life: The picoPSU-120 with Mini-Fit JR is marked for long life production and is guaranteed to have a life cycle of 5 years or more.

Notes: Not suitable for use with batteries, unstable power sources or voltages other than 12V.

CE / FCC / VCCI Certifications: EN55024, EN55022 Class B (CE certification), Australia/New Zealand (using CISPR 22, EN55022), Japan (VCCI: using CISPR 22, ANSI C63.4), United States (FCC Part 15, Subpart B, Class B), Canada (ICES-003 using CISPR 22, ANSI C63.4).

Installation Guide

The picoPSU-150-XT plugs directly into a motherboard ATX connector and measures just 31x53x15mm - about the size of two AA batteries. The picoPSU-150-XT generates up to 150 Watts of power from a 12V DC supply, at over 96% efficiency. An attached cable harness provides:

• 24pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• 12V P4 Power

Compatibility: The picoPSU-150-XT can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. Additionally most Mini-ITX boards with Intel and AMD processors up to around 95W TDP can be powered, with a 150W or 192W Adapter. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you. Compatible Universal AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter
• 150W AC Adapter 4-pin*
• 192W AC Adapter 4-pin*

*The 2.5/5.5mm Jack can be replaced with the more robust 4-pin Mini-DIN connector that is supplied with our 150W and 192W AC Adapters.

Adding more SATA drives: The picoPSU-150-XT has one SATA connector and a Molex connector. To power more SATA drives use the Peripheral Extension Cable or a Molex to SATA or 2x SATA cable.

24pin ATX and P4 Power Connector provided: The picoPSU-150-XT is ready to use with boards such as the Asus E35M1-I Deluxe, Gigabyte E350N-USB3, GA-H67N-USB3-B3, Intel D425KT, D525MW, DH67CFB3, DQ67EPB3, Sapphire Pure Fusion Mini E350, Zotac E350-A-E, H67-ITX-C-E and many others (check board listings - boards with 20pin ATX connectors will not work with the picoPSU-150-XT).

Long Life: The picoPSU-150-XT is marked for long life production and is guaranteed to have a life cycle of 5

Notes: Not suitable for use with batteries, unstable power sources or voltages other than 12V.

Installation Guide

The picoPSU-160-XT plugs directly into a motherboard ATX connector and measures just 31x53x15mm - about the size of two AA batteries. The picoPSU-160-XT generates up to 160 Watts (200 Watts peak) of power from a 12V DC supply. An attached cable harness provides:

• 24pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• 12V P4 Power

Compatibility: The picoPSU-160-XT can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. Additionally most Mini-ITX boards with Intel and AMD processors up to around 95W TDP can be powered, with a 150W or 192W Adapter. The picoPSU-160-XT is currently our most powerful picoPSU. If you are considering using with a board not on our site, please email us to check compatibility.

12V AC Adapter Required: You will need a 12V AC Adapter to use this picoPSU. Please read their product listings to determine which is most suitable for you. Compatible Universal AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter
• 150W AC Adapter 4-pin*
• 192W AC Adapter 4-pin*

*The 2.5/5.5mm Jack can be replaced with the more robust 4-pin Mini-DIN connector that is supplied with our 150W and 192W AC Adapters.

Adding more SATA drives: The picoPSU-160-XT has one SATA connector and a Molex connector. To power more SATA drives use the Peripheral Extension Cable or a Molex to SATA or 2x SATA cable.

24pin ATX and P4 Power Connector provided: The picoPSU-160-XT is ready to use with boards such as the Asus E35M1-I Deluxe, Gigabyte E350N-USB3, GA-H67N-USB3-B3, Intel D425KT, D525MW, DH67CFB3, DQ67EPB3, Sapphire Pure Fusion Mini E350, Zotac E350-A-E, H67-ITX-C-E and many others (check board listings - boards with 20pin ATX connectors will not work with the picoPSU-160-XT).

Long Life: The picoPSU-160-XT is marked for long life production and is guaranteed to have a life cycle of 5

Notes: Not suitable for use with batteries, unstable power sources or voltages other than 12V.

Installation Guide

The picoPSU-120-WI-25 plugs directly into a motherboard ATX connector and measures just 31x45x20mm - about the size of two AA batteries. The picoPSU-120-WI-25 generates up to 80 Watts of power (120 Watts peak) from a regulated 12-25V DC supply, at over 94% efficiency. An attached cable harness provides:

• 20pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• Molex Floppy Power

Compatibility: The picoPSU-120-WI-25 can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. Additionally some lower power consumption Mini-ITX boards with Intel and AMD processors up to around 45W TDP can be powered. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

Compatible AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter
• 150W AC Adapter 4-pin*
• 192W AC Adapter 4-pin*

*The 2.5/5.5mm Jack can be replaced with the more robust 4-pin Mini-DIN connector that is supplied with our 150W and 192W AC Adapters.

Adding more SATA drives: The picoPSU-120-WI-25 has one SATA connector and a Molex connector. To power more SATA drives use a Molex to SATA or 2x SATA cable.

P4 Power Connectors: If your board has a 4-pin 12V P4 power connector, you will need to use a Molex to 12V P4 Power Cable, or a different picoPSU.

Regulated Voltage Required: A stable and regulated voltage of between 12 and 25 Volts is required to use this picoPSU, connected by a standard 2.5mm /5.5mm DC Jack or Mini-Fit JR connector. Our 12V AC Adapters are suitable for this picoPSU. Please read their product listings to determine which is most suitable for you.

Long Life: The picoPSU-120-WI-25 is marked for long life production and is guaranteed to have a life cycle of 5 years or more.

Notes: Not suitable for use with batteries or unregulated power sources.

Installation Guide

The picoPSU-80-WI-32 plugs directly into a motherboard ATX connector and measures just 31x45x20mm - about the size of two AA batteries. The picoPSU-80-WI-32 generates up to 80 Watts of power (120 Watts peak) from a regulated 12-32V DC supply, at over 93% efficiency. An attached cable harness provides:

• 20pin ATX Connector
• SATA Power Connector
• Molex (ATA) HDD Power
• Molex Floppy Power

Compatibility: The picoPSU-80-WI-32 can power all our Mini-ITX boards with Geode, C3, C7, Atom and Fusion processors. Additionally some lower power consumption Mini-ITX boards with Intel and AMD processors up to around 45W TDP can be powered. More powerful picoPSUs offer more headroom for additional devices. If you are considering using with a board not on our site, please email us to check compatibility.

Compatible AC Adapters:

• 60W AC Adapter
• 80W AC Adapter
• 110W AC Adapter
• 150W AC Adapter
• 150W AC Adapter 4-pin*
• 192W AC Adapter 4-pin*

*The 2.5/5.5mm Jack can be replaced with the more robust 4-pin Mini-DIN connector that is supplied with our 150W and 192W AC Adapters.

Adding more SATA drives: The picoPSU-80-WI-32 has one SATA connector and a Molex connector. To power more SATA drives use a Molex to SATA or 2x SATA cable.

P4 Power Connectors: If your board has a 4-pin 12V P4 power connector, you will need to use a Molex to 12V P4 Power Cable, or a different picoPSU.

Regulated Voltage Required: A stable and regulated voltage of between 12 and 32 Volts is required to use this picoPSU, connected by a standard 2.5mm /5.5mm DC Jack or Mini-Fit JR connector. Our 12V AC Adapters are suitable for this picoPSU. Please read their product listings to determine which is most suitable for you.

Long Life: The picoPSU-80-WI-32 is marked for long life production and is guaranteed to have a life cycle of 5 years or more.

Notes: Not suitable for use with batteries or unregulated power sources.

Installation Guide

Universal 12V DC 60W 5A AC Adapter suitable for use with any of our picoPSU DC-DC Converters, and Mini-ITX Motherboards with 12V DC Input. Also suitable as an upgrade, replacement or spare part for many enclosures that require 12V DC Input (e.g. M200, M300, M350, most Morex cases, several 60W/80W Travla Cases, and many others).

Most commonly paired with the following picoPSUs:

• picoPSU-80
• picoPSU-90
• picoPSU-90-XLP

Suitable for use with the following motherboards with 12V DC Input:

• D945GSEJT
• JNF92-270
• JNC96-525
• JNC98-525
• P820-12L

Notes: This 12V AC Adapter is *not* compatible with 90W/120W Travla Cases or as a replacement for Zotac or Asus AC Adapters, as these require a 19V power input. This Adapter is fanless. Larger capacity AC Adapters provide more headroom and could extend the life of your components. Full size (5.25in) optical drives draw a lot of power at startup - use 110W or larger AC Adapter with picoPSU-120 or larger. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter can be bundled with UK, Euro and USA style power cables. Universal adapter - will work with any voltage 110 - 240V.

Universal 12V DC 80W 6.6A AC Adapter suitable for use with any of our picoPSU DC-DC Converters, and Mini-ITX Motherboards with 12V DC Input. Also suitable as an upgrade, replacement or spare part for many enclosures that require 12V DC Input (e.g. most Morex cases, several 60W/80W Travla Cases, and many others).

Most commonly paired with the following picoPSUs:

• picoPSU-80
• picoPSU-90
• picoPSU-90-XLP

Suitable for use with the following motherboards with 12V DC Input:

• D945GSEJT
• JNF92-270
• JNC96-525
• JNC98-525
• P820-12L

Notes: This 12V AC Adapter is *not* compatible with 90W/120W Travla Cases or as a replacement for Zotac or Asus AC Adapters, as these require a 19V power input. This Adapter is fanless, and has a blue LED. Larger capacity AC Adapters provide more headroom and could extend the life of your components. Full size (5.25in) optical drives draw a lot of power at startup - use 110W or larger AC Adapter with picoPSU-120 or larger. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter can be bundled with UK, Euro and USA style power cables. Universal adapter - will work with any voltage 110 - 240V.

Universal 12V DC 110W 9A AC Adapter suitable for use with any of our picoPSU DC-DC Converters, and Mini-ITX Motherboards with 12V DC Input. Also suitable as an upgrade, replacement or spare part for many enclosures that require 12V DC Input (e.g. M200, M300, M350, most Morex cases, several 60W/80W Travla Cases, and many others).

Most commonly paired with the following picoPSUs:

• picoPSU-80
• picoPSU-90
• picoPSU-90-XLP
• picoPSU-120
• picoPSU-120 Mini-Fit

Suitable for use with the following motherboards with 12V DC Input:

• D945GSEJT
• JNF92-270
• JNC96-525
• JNC98-525
• P820-12L

Notes: This 12V AC Adapter is *not* compatible with 90W/120W Travla Cases or as a replacement for Zotac or Asus AC Adapters, as these require a 19V power input. This Adapter contains a small, very quiet fan. Larger capacity AC Adapters provide more headroom and could extend the life of your components. Full size (5.25in) optical drives draw a lot of power at startup - use 110W or larger AC Adapter with picoPSU-120 or larger. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter can be bundled with UK, Euro and USA style power cables. Universal adapter - will work with any voltage 110 - 240V.

Universal 12V DC 150W 12.5A AC Adapter suitable for use *only* with the following picoPSU DC-DC Converters using the provided 4pin Mini-DIN to Mini-FIT JR Adapter:

• picoPSU-160-XT
• picoPSU-150-XT
• picoPSU-120 with Mini-Fit
• picoPSU-120 WI 12-25V
• picoPSU-80 WI 12-32V

Notes: Adapter is fanless. Cannot be used with circular chassis panel mount holes (e.g. on the M200, M300, M350 enclosures) without case modification. Larger capacity AC Adapters provide more headroom and could extend the life of your components. Full size (5.25in) optical drives draw a lot of power at startup - use 110W or larger AC Adapter with picoPSU-120 or larger. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter can be bundled with UK, Euro and USA style power cables. Universal adapter - will work with any voltage 110 - 240V.

Universal 12V DC 150W 12.5A AC Adapter suitable for use with any of our picoPSU DC-DC Converters, and Mini-ITX Motherboards with 12V DC Input. Also suitable as an upgrade, replacement or spare part for many enclosures that require 12V DC Input (e.g. M200, M300, M350, most Morex cases, several 60W/80W Travla Cases, and many others).

Most commonly paired with the following picoPSUs:

• picoPSU-80
• picoPSU-90
• picoPSU-90-XLP
• picoPSU-120
• picoPSU-120 Mini-Fit
• picoPSU-150-XT
• picoPSU-160-XT

Suitable for use with the following motherboards with 12V DC Input:

• D945GSEJT
• JNF92-270
• JNC96-525
• JNC98-525
• P820-12L

Notes: This 12V AC Adapter is *not* compatible with 90W/120W Travla Cases or as a replacement for Zotac or Asus AC Adapters, as these require a 19V power input. This Adapter is fanless, and has a blue LED. *Can* be used with circular chassis panel mount holes (e.g. on the M200, M300, M350 enclosures) without case modification. Larger capacity AC Adapters provide more headroom and could extend the life of your components. Full size (5.25in) optical drives draw a lot of power at startup - use 110W or larger AC Adapter with picoPSU-120 or larger. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter can be bundled with UK, Euro and USA style power cables. Universal adapter - will work with any voltage 110 - 240V.

Specifications: Operating Temperature: 0C~40C; Operating Humidity: 20%~80%, RH, Non-condensing; Storage Temperature: -20°C~80°C; Storage Humidity: 10%~90%, RH, Non-condensing; Dimensions: 171 x 72 x 42mm; Meets Energy Star EPS 2.0 /ErP Lot 7; Average Efficiency > 87%; No Load Power Consumption < 0.5W; PFC: Active; MTBF Min. 100,000 hours at full load at 25°C ambient, predicated by MIL-HDBK-217F

Universal 12V DC 19W 16A AC Adapter suitable for use *only* with the following picoPSU DC-DC Converters using the provided 4pin Mini-DIN to Mini-FIT JR Adapter:

• picoPSU-160-XT
• picoPSU-150-XT
• picoPSU-120 with Mini-Fit
• picoPSU-120 WI 12-25V
• picoPSU-80 WI 12-32V

Notes: Adapter is fanless. Cannot be used with circular chassis panel mount holes (e.g. on the M200, M300, M350 enclosures) without case modification. Full size (5.25in) optical drives draw a lot of power at startup - use the 192W AC Adapter with a picoPSU-120, picoPSU-150X-XT or picoPSU-160-XT. Always email us to check compatibility if you do not intend to use with Mini-ITX equipment.

This adapter comes with a UK power cable as standard. A Euro or US Power cable can be added. Universal adapter - will work with any voltage 110 - 240V.

Designed to provide power and to control the ON/OFF switch of a motherboard (PC) based on ignition status, M2-ATX is a wide input (6-24V) vehicle or car DC-DC ATX power supply capable of surviving tough car engine cranks (down to 5.7V) as well as transient over-voltage situations.

8 user selectable microcontroller driven timing modes, allowing you to choose up to 8 ignition/shutdown vehicle / car timing schemes. While in deep sleep mode, M2-ATX constantly monitors your car battery voltage levels, automatically shutting down until battery levels reach safe levels.

M2-ATX comes equipped with ATX, Molex HDD, SATA HDD and Floppy cable harness, jumpers, faston connectors and 2 pin cables for motherboard ON/OFF switch. Just connect it to your 12V or 24V car/boat/RV battery and power up your PC.

Designed to work with your own projects or the VoomPC and VoomPC 2, but is also a direct size compatible replacement with Morex 26xx, 27xx, 36xx, Travla C134, C150, C158, C159, Compact Wall Mount and Tranquil T2e cases.Dimensions: 45mm x 160mm (1.77in x 6.31in). 160W Output - ideal for Socket Mini-ITX boards.ITX Not compatible with EPIA PD boards.

*Notes: If your board has a 4 pin 12V P4 power connector, you will need add a Molex to 12V P4 Power Cable or 12V P4 to 12V P4 Power Extension Cable.

Product Manual (PDF)

Designed to provide power and to control the ON/OFF switch of a motherboard (PC) based on ignition status, M2-ATX-HV is a wide input (6-32V) vehicle or car DC-DC ATX power supply capable of surviving tough car engine cranks (down to 5.7V) as well as transient over-voltage situations.

8 user selectable microcontroller driven timing modes, allowing you to choose up to 8 ignition/shutdown vehicle / car timing schemes. While in deep sleep mode, M2-ATX-HV constantly monitors your car battery voltage levels, automatically shutting down until battery levels reach safe levels.

M2-ATX-HV comes equipped with ATX, Molex HDD, SATA HDD and Floppy cable harness, jumpers, faston connectors and 2 pin cables for motherboard ON/OFF switch. Just connect it to your 12V or 24V car/boat/RV battery and power up your PC.

Designed to work with your own projects or the VoomPC and VoomPC 2, but is also a direct size compatible replacement with Morex 26xx, 27xx, 36xx, Travla C134, C150, C158, C159, Compact Wall Mount and Tranquil T2e cases.Dimensions: 45mm x 160mm (1.77in x 6.31in). 160W Output - ideal for Socket Mini-ITX boards.ITX Not compatible with EPIA PD boards.

*Notes: If your board has a 4 pin 12V P4 power connector, you will need add a Molex to 12V P4 Power Cable or 12V P4 to 12V P4 Power Cable.

Product Manual (PDF)

Designed to provide power and to control the ON/OFF switch of a motherboard (PC) based on ignition status, M3-ATX is a wide input (6-24V) vehicle or car DC-DC ATX power supply capable of surviving tough car engine cranks (down to 6V) as well as transient over-voltage situations.

The M3-ATX is based on an electrically similar design to the M2-ATX but with dramatic size reductions (picoPSU plug-in style).

• 125 Watts (150watt peak) PSU
• 20pin ATX, 6-24V wide input range
• Programmable timing settings using optional serial harness and utility
• Intelligent shutdown controller
• ON/OFF motherboard control
• Survives vehicle engine cranks
• Battery deep discharge prevention
• High efficiency, 125 watts output
• "Anti-Thump" Amplifier remote control
• < 0.5mA standby current
• Solid Japanese Polymer capacitors

M3-ATX comes equipped with a ATX, Molex HDD, SATA HDD and Floppy cable harness, jumpers, faston connectors and cables for Thump and Motherboard ON/OFF switch. Just connect to your 12V or 24V car/boat/RV battery and power up your PC.

Programmable shutdown / sleep modes via optional serial cable; Fits any motherboard equipped with a 20 or 24pin ATX connector; 100% silent, fanless, no moving parts; Operates from 6-24V; Multi-chemistry batteries supported; Highly efficient design - does not produce a lot of heat; Ideal for low power Intel Core processors as well as all Atom, VIA or AMD processors.

*Note: If your board has a 4 pin 12V P4 power connector, you will need add a Molex to 12V P4 Power Cable. Not compatible with Zotac NM10-E board due to positioning of P4 connector on board.

M3-ATX Manual

M3-ATX Timing Settings

Designed to provide power and to control the ON/OFF switch of a motherboard (PC) based on ignition status, M3-ATX-HV is a very wide input (6-34V) vehicle or car DC-DC ATX power supply capable of surviving tough car engine cranks (down to 6V) as well as transient over-voltage situations.

The M3-ATX-HV is based on an electrically similar design to the M2-ATX but with dramatic size reductions (picoPSU plug-in style).

• 95 Watts (120watt peak) PSU
• 20pin ATX, 6-34V wide input range
• Programmable timing settings using optional serial harness and utility
• Intelligent shutdown controller
• ON/OFF motherboard control
• Survives vehicle engine cranks
• Battery deep discharge prevention
• "Anti-Thump" Amplifier remote control
• Low standby current
• Solid Japanese Polymer capacitors

M3-ATX-HV comes equipped with a ATX, Molex HDD, SATA HDD and Floppy cable harness, jumpers, faston connectors and cables for Thump and Motherboard ON/OFF switch. Just connect to your 12V or 24V car/boat/RV battery and power up your PC.

Programmable shutdown / sleep modes via optional serial cable; Fits any motherboard equipped with a 20 or 24pin ATX connector; 100% silent, fanless, no moving parts; Operates from 6-34V; Multi-chemistry batteries supported; Highly efficient design - does not produce a lot of heat; Ideal for low power Intel Core processors as well as all Atom, VIA or AMD processors.

*Note: If your board has a 4 pin 12V P4 power connector, you will need add a Molex to 12V P4 Power Cable. Not compatible with Zotac NM10-E board due to positioning of P4 connector on board.

M3-ATX-HV Manual

M3-ATX Timing Settings

Replacement 300W Ultra Quiet 80 PLUS FlexATX PSU.

Suitable as an extremely low noise upgrade for our C1-RACK chassis, or as a spare part for our C2-RACK chassis. Not suitable for any other 1U chassis we stock due to dimension differences.

Power Connectors: 20pin ATX; 4pin ATX; 4pin 12V P4; 4x SATA; 1x Molex; 1x Floppy; 4x 3pin Chassis Fan.

Specifications: MTBF: 100,000 hours on maximum load at +25°C; Efficiency: typical up to 84%; Leakage Current: Less than 3.5mA at 264Vac, 50Hz; Temperature Range: Operating: 0°C to +50°C full load; storage & shipping: -20°C to +80°C; Dimensions: 190 x 100 x 41mm

Input Characteristics: Input Range: 90 - 264Vac; Full Range Input Frequency: 47 - 63Hz; Input Current: Max 5A @ 115Vac, 3A@ 230Vac

Output Characteristics:

Certifications: RoHS Compliant; Complies with FCC part 15 subpart J class B 115Vac operation and CISPR 22 class B at 230Vac operation; Approved by UL/CUL6095-1, TUV EN60950-1, CB,EMC,FCC; Compatible with European Union Directive 2002/95/EC (Restriction on Hazardous Substances); Active Power Factor Correction (PFC) meets EN61000-3-2.

Splitter cable converts one Molex HDD connector into two, allowing you to power additional devices.

Please consider the total load on your system when adding devices.

Splitter cable converts one Molex HDD connector into a HDD connector and a floppy connector, allowing you to power that extra compact flash adapter or slimline optical drive.

Please consider the total load on your system when adding devices.

Most PSUs (including all the PSUs on Mini-ITX Cases we sell) come with standard 4-pin Molex connectors for connection to IDE ATA Hard Drives.

To power a Serial ATA drive from one of our cases, you will require this adapter cable.

Use this cable to add an additional 2x SATA power connectors to any power supply with a spare Molex HDD connection.

If more SATA connections are required please use the 2x Molex HDD Power Splitter cable above to provide more Molex HDD connectors.

Please consider the total load on your system when adding devices.

Short (48mm) Molex HDD to 4-pin 12V P4 Power Connector Cable.

Compatibility: Suitable for Mini-ITX motherboards that require a P4 power connection, combined with a PSU without a P4 connector but with a spare HDD connector.
