Dynatron K2 1U Side Blower Cooler suitable for Intel Socket 115x & 1200 Boards

Dynatron K2 1U Intel Cooler
£29.00
£34.80 inc. VAT
IN STOCK (Checked 16:24)

Dynatron K2 Low Profile, 27.8mm High Side Blower Cooler suitable for fitting Intel Socket 1150, 1151, 1155, 1156 and 1200 motherboards with up to 73W TDP processors into a 1U Chassis.

Long life two-ball bearing fan draws the cool air though the fins and extracts hot air to one side to support chassis airflow. Intel approved push pins provide maximum compatibility. Pre-applied high performance TIG830SP thermal compound ensures clean and easy installation.

Case Compatibility: Side Blower design suitable for use in a 1U chassis. Tip: angle the K2 to force air out of the rear of the chassis.

Compatible Motherboards: All Intel Socket 1150, 1151, 1155, 1156 and 1200 Mini-ITX Motherboards with up to 73W TDP Processor fitted.

Installation Tip: Configure your BIOS to run at 40% fan duty up to 50C for quieter operation.

Specifications: Fan speed: 1000 RPM (at 20% Duty Cycle); 2500 RPM (at 50%); 4000 RPM (at 100%) (PWM controlled); Airflow: 8.3 CFM (at 50%) - 11.9 CFM (at 100%); Air Pressure: 0.087 inch-H2O (at 20%); 0.453 inch-H2O (at 50%); 0.929 inch-H2O (at 100%); Noise level: 37.8 dBA (at 50%) - 44.0 dbA (at 100%); Power Consumption: 0.6 W (at 20%); 1.8 W (at 50%); 4.8 W (at 100%); Weight: 380g; Fan Dimensions: 75 x 75 x 15mm; Overall Dimensions: 82.6 x 81 x 27.8 (H) mm.

Specifications
Brand Dynatron
Model K2 1U Intel Cooler
Maximum TDP 73W
Connector Type 4-pin PWM
Socket Types 1150, 1151, 1155, 1156, 1200
Cooling
Fan Speed 600-3000 RPM (PWM Controlled)
Operating Temperature -10℃ - 65℃
Storage Temperature -30℃ - 70℃
Max Airflow 11.9 CFM
Max Air Pressure 23.5966 mmH2O
Noise Level 44dB(A)
Dimensions
Fan Size 75 x 15 x 75mm (W x D x H)
Heatsink Height 27.8mm
W x D x H 82.6 x 81 x 27.8mm
Volume 0.19 litres
Weight 380g
*Data obtained directly from Dynatron, Mini-ITX assumes no responsibility or liability for any errors or omissions
