LCD Displays

20x2 Pico-LCD Auxiliary Display Kit and USB Connectors
256x64 Pico-LCD Auxiliary Display Kit and USB Connectors

20x2 Pico-LCD Auxiliary Display Kit and USB Connectors

20x2 Pico-LCD Display Kit and USB Connectors
£39.00
  £46.80 inc. VAT
  IN STOCK (Checked 11:34 BST)


Pico-LCD is an intelligent 2x20 character USB LCD display module with InfraRed receiver and keypad interface. True USB HID device (not serial or parallel port to USB emulated) supporting high speed data transfers and easy application development without any special drivers needed. Can also be connected through I2C or USART.

Pico-LCD has built in 8x5 dots ASCII character font with 8 used definable characters and provides 8 GPO (General Purpose Output) pins. Internal EEPROM allows firmware upgrading and splash screen definition. On power on Pico-LCD is able to show up to 10 user defined splash screns with custom timing, order and LED/GPO status.

Sample applications provide Windows and Linux platform support with open source code and SDK available on our drivers page.

Provided with two USB cables for internal connection to a USB pin header or external connection to a USB socket.

Specifications: Display Dimensions: 19 x 83mm (0.74 x 3.28 in). Pico-LCD Dimensions: 37 x 116mm (1.47 x 4.57 in).

256x64 Pico-LCD Auxiliary Display Kit and USB Connectors

256x64 Pico-LCD Display Kit and USB Connectors
£69.00
  £82.80 inc. VAT
Lead time usually 1-2 weeks


Pico-LCD is a 256x64 pixel USB LCD backlit display module suitable for displaying real time graphics, system status, stocks, weather, RSS feeds, music information, news and sports updates with Vista Sideshow or Linux drivers on a 2nd dedicated LCD display. Monitor MRTG generated graphics from any remote systems and create your own python scripts for displaying your data (included in Linux package).

This device is compatible with Windows 7 & Vista sideshow. Linux is well-supported and this device has the ability to work with all LCD4Linux plugins as well as the facility to output MRTG graphs. The device can be programmed with a custom boot logo.

Compatibility: Windows XP, Vista & 7 (32-bit) and Linux (32/64-bit).

Sample applications provide Windows and Linux platform support with open source code and SDK available on our drivers page.

Provided with two USB cables for internal connection to a USB pin header or external connection to a USB socket.

The unit is designed for use in projects and does not come with any mounting or bracket.

Specifications: Display Dimensions: 39 x 121mm (1.55 x 4.77 in). Pico-LCD Dimensions: 39 x 137 x 14mm (1.55 x 5.39 x 0.56 in).
