Dual LAN Barebones

Dual LAN Barebones (just add RAM and Storage)
Jetway JBC311 Dual Intel LAN Fanless NUC Form Factor PC
Jetway JBC320 Dual Intel LAN Fanless NUC Form Factor PC
Jetway JBC365 Dual LAN Barebones System
Jetway JBC375 Dual LAN, 4x Serial Port Barebones System
VIA ARTiGO A1200 Fanless, Dual LAN, Dual Serial Slim PC

Dual LAN Barebones with WiFi
Jetway JBC311W WiFi Dual Intel LAN Fanless NUC Form Factor PC
Jetway JBC320W WiFi Dual Intel LAN Fanless NUC Form Factor PC
Jetway JBC365W WiFi Dual LAN Barebones System
Jetway JBC375W WiFi Dual LAN, 4x Serial Port Barebones System

Jetway JBC311 Fanless NUC Form Factor PC with Intel N2930 Quad Core CPU and Dual Intel LAN

Jetway JBC311 Fanless NUC Form Factor Dual LAN PC
£165.00
  £198.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)


More images of the JBC311

You may also require:

2GB DDR3L 1600 SODIMM for JBC311*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC311*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC311*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:

Euro Power Cable for JBC311
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC311
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Tiny and Fanless Jetway JBC311 Barebones NUC Form Factor PC with Intel N2930 Bay Trail-M processor, 2x Intel 82583V Gigabit LAN, 2x HDMI, 3x USB 2.0, 1x USB 3.0, Serial Port and Wall/VESA mounting bracket included. Barebones unit - simply add a stick of DDR3L SODIMM memory and an mSATA drive to complete the internals of the JBC311.

Long Life: Product availability forecasted to at least 2019.

The JBC311 is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 101mm x 101mm NUC Form Factor motherboard. Stylish solid aluminium construction with external AC Adapter.

Bays: 1x full size mSATA drive slot; 1x half size Mini-PCI Express Slot.

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch; Power LED; HDD LED; 1x USB 3.0; 1x USB 2.0; RS232/422/485 Serial Port.

Rear Panel: Kensington Lock Hole; Combined 3.5mm Audio Line Out and S/PDIF; 2x USB 2.0; 2x HDMI; 2x Intel 82583V Gigabit Ethernet; 9V ~ 24V power socket (connects to supplied 12V, 36W AC Adapter); 2x WiFi Antenna connections (Antenna provided); Cooling vents (sealed as standard, can be removed to aid cooling in hot environments).

Cooling: The JBC311 is a fanless device with integrated heatsink fins on the top and sides of the chassis and optional cooling vents on the rear. The JBC311 can be operated in temperatures of 0C to 40C with appropriate airflow.

Power supply: Universal 100-240V External 36W AC Adapter with UK power cord connects to 12V power socket.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Accessories: JBC311; AC Adapter; UK Power Cord (other power cords available); Screw pack; Driver DVD; Manual; Assembly Guide; Wall & VESA & DIN Mounting kit; DIN Rail clip.

Measurements: 116 x 49 x 110 mm / 4.57 x 1.923 x 4.33in (W x H x D); Volume: 0.625 litres.

*Note: The JBC311 supports up to 8GB DDR3L memory on a 1.35V DDR3L SODIMM.This is not compatible with DDR, DDR2 or standard DDR3 SODIMM memory.

Jetway JBC320 Fanless NUC Form Factor PC with Intel N2930 Quad Core CPU, Dual Intel LAN, mSATA & 2.5in Drive Support

Jetway JBC320 Fanless NUC Form Factor Dual LAN PC
£175.00
  £210.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)



More images of the JBC320

You may also require:

2GB DDR3L 1600 SODIMM for JBC320*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC320*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC320*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:

Euro Power Cable for JBC320
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC320
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Tiny and Fanless Jetway JBC320 Barebones NUC Form Factor PC with Intel N2930 Bay Trail-M processor, 2x Intel 82574L Gigabit LAN, 2x HDMI, 3x USB 2.0, 1x USB 3.0, Serial Port and Wall/VESA mounting bracket included. Barebones unit with 2 storage bays - simply add a stick of DDR3L SODIMM memory and an mSATA and/or 2.5in SSD/HDD drive to complete the internals of the JBC320.

The JBC320 can be considered to be a 16mm taller version of the JBC311, with the addition of a 2.5in SSD/HDD drive bay.

Long Life: Product availability forecasted to at least 2019.

The JBC320 is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 101mm x 101mm NUC Form Factor motherboard. Stylish solid aluminium construction with external AC Adapter.

Bays: 1x full size mSATA drive slot; 1x half size Mini-PCI Express Slot (occupied by WiFi card on WiFi version); 1x 2.5in SSD/HDD bay.

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch; Power LED; HDD LED; 1x USB 3.0; 1x USB 2.0; RS232/422/485 Serial Port& 5V/12V Selectable.

Rear Panel: Kensington Lock Hole; Combined 3.5mm Audio Line Out and S/PDIF; 2x USB 2.0; 2x HDMI; 2x Intel 82583V Gigabit Ethernet; 9V ~ 24V power socket (connects to supplied 12V, 36W AC Adapter); 2x WiFi Antenna connections (sealed on non-WiFi unit); Cooling vents (sealed as standard, can be removed to aid cooling in hot environments - careful disassembly of unit required).

Cooling: The JBC320 is a fanless device with integrated heatsink fins on the top and sides of the chassis and optional cooling vents on the rear. The JBC320 can be operated in temperatures of 0C to 40C with appropriate airflow.

Power supply: Universal 100-240V External 36W AC Adapter with UK power cord connects to 12V power socket. Power socket supports wide range 9-24V regulated input.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Accessories: JBC320; AC Adapter; UK Power Cord (other power cords available); Screw pack; Driver DVD; Manual; Assembly Guide; Wall & VESA & DIN Mounting kit; DIN Rail clip.

Measurements: 116 x 65 x 110 mm / 4.57 x 2.56 x 4.33in (W x H x D); Volume: 0.829 litres.

*Note: The JBC320 supports up to 8GB DDR3L memory on a 1.35V DDR3L SODIMM.This is not compatible with DDR, DDR2 or standard DDR3 SODIMM memory.

Jetway JBC365 Fanless Dual LAN PC with Intel N2930 Quad Core CPU and 2.5in Support

Jetway JBC365 Fanless NUC Form Factor Dual LAN PC
£160.00
  £192.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)


More images of the JBC365

You may also require:

2GB DDR3L 1600 SODIMM for JBC365*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC365*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC365*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:

Add a 2.5in SSD or HDD:

Euro Power Cable for JBC365
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC365
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Incredibly small Jetway JBC365 Barebones Mini-PC with Quad Core Bay Trail Processor and Dual Realtek RTL8111G Gigabit LAN ports. Barebones unit - simply add a stick of DDR3L SODIMM memory and a 2.5in HDD/SSD and/or mSATA drive to complete the internals of the JBC365.

The JBC365 is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 3.5in SBC motherboard measuring just 148 x 102mm. The stylish industrial chassis is provided with AC Adapter and vertical stand, and supports both mSATA and a 2.5in hard drive or SSD internally.

Bays: 1x 2.5in SATA SSD or HDD drive bay (SATA Cable included, max height 9.5mm - WD 2TB not compatible); 1x mSATA/Mini PCI Express drive bay; 1x Half Mini PCI-Express slot (occupied by WiFi card in the WiFi version of this system)

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch, Power LED, HDD LED.

Rear Panel: 12V power socket (connects to supplied 60W AC Adapter); 2x USB 2.0; 2x Realtek RTL8111G Gigabit LAN; DVI-I port (VGA adapter included); 2x USB 3.0; 3.5mm Line-out port (Realtek ALC662 HD Audio); 1x Wi-Fi Antenna connector (unused).

Power supply: Universal 100-240V External 60W AC Adapter with UK power cord connects to 12V power socket.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Packing List: 1x JBC365; 1x AC Adapter; 1x Power Cable; 1x Installation CD; 1x Manual; 1x Screw Pack; 2x Din Rail Clips; 2x Metal Wall Mounts; 1x DVI-I to VGA Adapter; 2x ABS Feet.

Measurements: 152 x 111 x 37 mm / 5.98 x 4.37 x 1.46in (W x H x D); Volume: 0.624 litres.

Jetway JBC375 Fanless Dual LAN PC with Intel N2930 Quad Core CPU and 4x Serial Ports

Jetway JBC375 Fanless Quad Serial Barebones System
£190.00
  £228.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)


More images of the JBC375 Quad LAN Barebones

You may also require:

2GB DDR3L 1600 SODIMM for JBC375*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC375*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC375*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Euro Power Cable for JBC375
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC375
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:



Compact Jetway JBC375 Barebones Mini-PC with Dual Gigabit LAN, 4x Serial Ports, powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics. Barebones unit - simply add a stick of DDR3L SODIMM memory and a 2.5in HDD/SSD and/or mSATA drive to complete the internals of the JBC375. The JBC375 comes with wall-mount brackets as standard.

Bays: 1x 2.5in SATA SSD or HDD drive bay (SATA Cable included, max height 9.5mm); 1x mSATA/Mini PCI Express drive bay; 1x Half Mini PCI-Express slot (occupied by WiFi card in the WiFi version of this system)

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch, Reset switch, Power LED, HDD LED, 2x USB 2.0; 3.5mm Headphone Out, 3.5mm Mic In; 2x Serial Ports; Punch-out plates for 2x additional Serial Ports; 2x Punch-out plates for WiFi antenna.

Rear Panel: 12V power socket (connects to supplied 60W AC Adapter); 2x Punch-out plates for WiFi antenna; 2x USB 2.0; 2x Realtek RTL8111G Gigabit LAN; DVI-I port (VGA adapter included); 2x USB 3.0; 3.5mm Headphone-out port (Realtek ALC662 HD Audio); Punch-out plate for Serial Port.

Flexible Serial Port positioning: 4 Serial Ports are provided that can be distributed amongst 5 positions as required (1 in the front, 4 on the rear panel)

Power supply: Universal 100-240V External 60W AC Adapter with UK power cord connects to 12V power socket.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Packing List: 1x JBC375; 1x AC Adapter; 1x Power Cable; 1x Installation CD; 1x Manual; 1x Screw Pack; 2x Din Rail Clips; 2x Metal Wall Mounts; 1x DVI-I to VGA Adapter.

Measurements: 180 x 142 x 48 mm / 7.1 x 5.6 x 1.89in (W x H x D); Volume: 1.23 litres.

VIA ARTiGO A1200 Slim PC Kit: Fanless, Dual LAN, Dual Serial, WiFi Ready

Select Power Cable:

  SPECIAL OFFER - usually £299.00
£149.00
  £178.80 inc. VAT
  IN STOCK (Checked 02:27 GMT)




More images of the ARTiGO A1200

You may also require:

2GB DDR3 1333 SODIMM for A1200
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3 1333 SODIMM for A1200
£32.00
  £38.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Configure your own ARTiGO A1200 Fanless slim PC Kit

The VIA ARTiGO A1200 Fanless slim PC Kit packs HD Video, HDMI and full Dual Core 64-bit computing in a slim Aluminium chassis.

Motherboard specification: 1.0GHz VIA Nano™ X2 64-bit Processor - 800 MHz Front Side Bus and 2MB L2 cache memory; VIA VX900H Media System chipset with Integrated VIA Chrome9™ HD DX9 3D/2D AGP graphics with MPEG-2, WMV9/VC1 & H.264 video decoding acceleration and DirectX 9.0 programmable graphics engine; Dual independent graphics outputs supported (VGA & HDMI); VIA VT2021 High Definition Audio; 2x VIA VT6130 Gigabit Ethernet controllers supporting WOL and PXE; 2x Serial Ports (Fintek F81801 LPC I/O Controller).

Storage Bays: 1x 2.5in SATA SSD or HDD drive bay (SATA Cable included); 1x CFast socket supports Type I/II CFast Flash Disks.

Memory: 1x 204-pin socket supports up to 4GB DDR3 1033 MHz SDRAM SODIMM

Front Panel: Power & HDD LEDs; Power switch; VGA Output (up to 2560 x 1600 supported); CFast Socket (behind panel); HDMI; 2x Gigabit LAN.

Rear Panel: DC 12V power input socket; 2x Serial Ports (RS232, COM1 optionally supports RS422/RS485); 4x USB 2.0; Line-out and Mic 3.5mm audio sockets.

Left side I/O panel: Two reserved antenna holes for WLAN & 3G Mini PCI-Express adapters (one Mini PCI-Express slot on motherboard).

Power supply: Universal 100-240V External AC Adapter connects to 12V power socket.

Power consumption: Typical 21W, maximum 27.5W.

Fanless operation: Innovative industrial buckled-blade thermal fin design provides reliable and stable performance in temperatures ranging from 0C~45C.

Supported operating systems: Windows 7, XP, Windows Embedded Standard 2009, Linux.

The complete VIA ARTiGO A1200 Package consists of: 1x ARTiGO A1200; 4x HDD screws; 1x External AC power adapter and Power Cord; 1x SATA ribbon cable; 1x Installation guide.

5 Minute Assembly: The A1200 comes pre-assembled. Remove the top of the unit to install RAM and a 2.5in SATA HDD or SSD.

Not included: RAM, hard drive, SSD, wireless device, operating system, VESA mount bracket and stands are not included, USB 3.0 is shown in publicity pictures but is an option for large orders only.

Measurements: 234 x 30 x 124 mm / 9.2in x 1.2in x 4.8in (W x H x D); Volume: 0.87 litres; Weight: 1.2 kg / 2.64lbs (without HDD).

Environmental Specification: 0C-45C Operating Temparature; -20C-60C Storage Temperature; 0%-90% Relative Humidity; .

Guides and Datasheets

Configure your own ARTiGO A1200 Fanless slim PC Kit

Build your own ARTiGO A1200 Dual LAN Slim PC System

Build your own ARTiGO A1200 System using the configurator below. If an item is out of stock it will be ordered for you. Please note: 300MBps WLAN operation requires 2x Antenna.

1 ARTiGO A1200 Barebone Pico-ITX Kit
£149.00
£150.00
£150.00
2 Memory
£0.00
£20.00
£32.00
3 2.5in SATA HDD or SSD Drive
4 Half Mini PCI-Express WLAN Card
£0.00

Lead time usually 3-5 days
£24.00
5 WLAN Antenna & Pigtail Kit
£0.00
£9.00
£12.00
5 WLAN Antenna & Pigtail Kit (2nd kit only required for 300Mbps operation)
£0.00
£9.00
£12.00

Jetway JBC311W WiFi Fanless NUC Form Factor PC with Intel N2930 Quad Core CPU and Dual Intel LAN

Jetway JBC311 Fanless NUC Form Factor Dual LAN PC
£175.00
  £210.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)


More images of the JBC311 WiFi

You may also require:

2GB DDR3L 1600 SODIMM for JBC311*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC311*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC311*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:

Euro Power Cable for JBC311
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC311
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Tiny and Fanless Jetway JBC311 Barebones NUC Form Factor PC with Intel N2930 Bay Trail-M processor, 2x Intel 82583V Gigabit LAN, 2x HDMI, 3x USB 2.0, 1x USB 3.0, Serial Port and Wall/VESA mounting bracket included. Wireless version adds 802.11 b/g/n WiFi & Bluetooth 4.0. Barebones unit - simply add a stick of DDR3L SODIMM memory and an mSATA drive to complete the internals of the JBC311.

Long Life: Product availability forecasted to at least 2019.

The JBC311 is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 101mm x 101mm NUC Form Factor motherboard. Stylish solid aluminium construction with external AC Adapter.

Bays: 1x full size mSATA drive slot; 1x half size Mini-PCI Express Slot (used by supplied WiFi card).

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch; Power LED; HDD LED; 1x USB 3.0; 1x USB 2.0; RS232/422/485 Serial Port.

Rear Panel: Kensington Lock Hole; Combined 3.5mm Audio Line Out and S/PDIF; 2x USB 2.0; 2x HDMI; 2x Intel 82583V Gigabit Ethernet; 9V ~ 24V power socket (connects to supplied 12V, 36W AC Adapter); 2x WiFi Antenna connections (Antenna provided); Cooling vents (sealed as standard, can be removed to aid cooling in hot environments).

Cooling: The JBC311 is a fanless device with integrated heatsink fins on the top and sides of the chassis and optional cooling vents on the rear. The JBC311 can be operated in temperatures of 0C to 40C with appropriate airflow.

Power supply: Universal 100-240V External 36W AC Adapter with UK power cord connects to 12V power socket.

Wireless: The Jetway JBC311 WiFi is fitted with an internal Half Mini PCI Express Realtek RTL8723BE chipset 802.11 b/g/n WiFi card & External Antenna.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Accessories: JBC311; AC Adapter; UK Power Cord (other power cords available); Screw pack; Driver DVD; Manual; Assembly Guide; Wall & VESA & DIN Mounting kit; DIN Rail clip; 2x WiFi Antenna.

Measurements: 116 x 49 x 110 mm / 4.57 x 1.923 x 4.33in (W x H x D); Volume: 0.625 litres.

*Note: The JBC311 supports up to 8GB DDR3L memory on a 1.35V DDR3L SODIMM.This is not compatible with DDR, DDR2 or standard DDR3 SODIMM memory.

Jetway JBC320W WiFi Fanless NUC Form Factor PC with Intel N2930 Quad Core CPU, Dual Intel LAN, mSATA & 2.5in Drive Support

Jetway JBC320W Fanless NUC Form Factor Dual LAN PC
£185.00
  £222.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)



More images of the JBC320W

You may also require:

2GB DDR3L 1600 SODIMM for JBC320W*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC320W*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC320W*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:

Euro Power Cable for JBC320W
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC320W
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Tiny and Fanless Jetway JBC320W Barebones NUC Form Factor PC with 802.11n WiFi, Intel N2930 Bay Trail-M processor, 2x Intel 82574L Gigabit LAN, 2x HDMI, 3x USB 2.0, 1x USB 3.0, Serial Port and Wall/VESA mounting bracket included. Barebones unit with 2 storage bays - simply add a stick of DDR3L SODIMM memory and an mSATA and/or 2.5in SSD/HDD drive to complete the internals of the JBC320W.

The JBC320W can be considered to be a 16mm taller version of the JBC311, with the addition of a 2.5in SSD/HDD drive bay.

Long Life: Product availability forecasted to at least 2019.

The JBC320W is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 101mm x 101mm NUC Form Factor motherboard. Stylish solid aluminium construction with external AC Adapter.

Bays: 1x full size mSATA drive slot; 1x half size Mini-PCI Express Slot (occupied by WiFi card); 1x 2.5in SSD/HDD bay.

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch; Power LED; HDD LED; 1x USB 3.0; 1x USB 2.0; RS232/422/485 Serial Port& 5V/12V Selectable.

Rear Panel: Kensington Lock Hole; Combined 3.5mm Audio Line Out and S/PDIF; 2x USB 2.0; 2x HDMI; 2x Intel 82583V Gigabit Ethernet; 9V ~ 24V power socket (connects to supplied 12V, 36W AC Adapter); 2x WiFi Antenna connections (Antenna provided); Cooling vents (sealed as standard, can be removed to aid cooling in hot environments - careful disassembly of unit required).

Cooling: The JBC320W is a fanless device with integrated heatsink fins on the top and sides of the chassis and optional cooling vents on the rear. The JBC320W can be operated in temperatures of 0C to 40C with appropriate airflow.

Power supply: Universal 100-240V External 36W AC Adapter with UK power cord connects to 12V power socket. Power socket supports wide range 9-24V regulated input.

Wireless: The Jetway JBC320 WiFi is fitted with an internal Half Mini PCI Express Realtek RTL8723BE chipset 802.11 b/g/n WiFi card & External Antenna.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Accessories: JBC320W; AC Adapter; UK Power Cord (other power cords available); Screw pack; Driver DVD; Manual; Assembly Guide; Wall & VESA & DIN Mounting kit; DIN Rail clip; 2x WiFi Antenna.

Measurements: 116 x 65 x 110 mm / 4.57 x 2.56 x 4.33in (W x H x D); Volume: 0.829 litres.

*Note: The JBC320W supports up to 8GB DDR3L memory on a 1.35V DDR3L SODIMM.This is not compatible with DDR, DDR2 or standard DDR3 SODIMM memory.

Jetway JBC365W WiFi Fanless Dual LAN PC with Intel N2930 Quad Core CPU and 2.5in Support

Jetway JBC365 WiFi Fanless NUC Form Factor Dual LAN PC
£170.00
  £204.00 inc. VAT
  IN STOCK (Checked 02:27 GMT)


More images of the JBC365

You may also require:

2GB DDR3L 1600 SODIMM for JBC365*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC365*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC365*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive*:

Add a 2.5in SSD or HDD:

Euro Power Cable for JBC365
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC365
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)


Incredibly small Jetway JBC365 Barebones Mini-PC with Quad Core Bay Trail Processor and Dual Realtek RTL8111G Gigabit LAN ports. Barebones unit - simply add a stick of DDR3L SODIMM memory and a 2.5in HDD/SSD and/or mSATA drive to complete the internals of the JBC365. Wireless version adds 802.11 b/g/n WiFi & Bluetooth 4.0.

The JBC365 is powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics on a 3.5in SBC motherboard measuring just 148 x 102mm. The stylish industrial chassis is provided with AC Adapter and vertical stand, and supports both mSATA and a 2.5in hard drive or SSD internally. The JBC365W Wireless version adds 802.11 b/g/n WiFi & Bluetooth 4.0 (not yet shown in our pictures).

Bays: 1x 2.5in SATA SSD or HDD drive bay (SATA Cable included, max height 9.5mm - WD 2TB not compatible); 1x mSATA/Mini PCI Express drive bay; 1x Half Mini PCI-Express slot (occupied by WiFi card in the WiFi version of this system)

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch, Power LED, HDD LED.

Rear Panel: 12V power socket (connects to supplied 60W AC Adapter); 2x USB 2.0; 2x Realtek RTL8111G Gigabit LAN; DVI-I port (VGA adapter included); 2x USB 3.0; 3.5mm Line-out port (Realtek ALC662 HD Audio); 1x Wi-Fi Antenna connector (unused).

Power supply: Universal 100-240V External 60W AC Adapter with UK power cord connects to 12V power socket.

Wireless: The Jetway JBC365 WiFi is fitted with an internal Half Mini PCI Express Realtek RTL8723BE chipset 802.11 b/g/n WiFi card & External Antenna.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Packing List: 1x JBC365; 1x AC Adapter; 1x Power Cable; 1x Installation CD; 1x Manual; 1x Screw Pack; 2x Din Rail Clipl; 2x Metal Wall Mounts; 1x DVI-I to VGA Adapter; 2x ABS Feet.

Measurements: 152 x 111 x 37 mm / 5.98 x 4.37 x 1.46in (W x H x D); Volume: 0.624 litres.

Jetway JBC375W Fanless Dual LAN PC with Intel N2930 Quad Core CPU and 4x Serial Ports and WiFi

Jetway JBC375 Fanless Quad Serial Barebones System
£200.00
  £240.00 inc. VAT
Lead time usually 1-2 weeks


More images of the JBC375W Quad LAN Barebones

You may also require:

2GB DDR3L 1600 SODIMM for JBC375*
£22.00
  £26.40 inc. VAT
  IN STOCK (Checked 02:27 GMT)

4GB DDR3L 1600 SODIMM for JBC375*
£33.00
  £39.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

8GB DDR3L 1600 SODIMM for JBC375*
£48.00
  £57.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Euro Power Cable for JBC375
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

US Power Cable for JBC375
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 02:27 GMT)

Add an mSATA drive:



Compact Jetway JBC375 Barebones Mini-PC with Dual Gigabit LAN, 4x Serial Ports, powered by a 1.83GHz Quad Core N2930 Celeron processor with Intel HD graphics. Barebones unit - simply add a stick of DDR3L SODIMM memory and a 2.5in HDD/SSD and/or mSATA drive to complete the internals of the JBC375. The JBC375 comes with wall-mount brackets as standard. Wireless version adds 802.11 b/g/n WiFi & Bluetooth 4.0 (antenna not shown in our picture).

Bays: 1x 2.5in SATA SSD or HDD drive bay (SATA Cable included, max height 9.5mm); 1x mSATA/Mini PCI Express drive bay; 1x Half Mini PCI-Express slot (occupied by WiFi card in the WiFi version of this system)

Memory: 1x 204-pin socket supports up to 8GB DDR3L 1.35V SODIMM.

Front Panel: Power switch, Reset switch, Power LED, HDD LED, 2x USB 2.0; 3.5mm Headphone Out, 3.5mm Mic In; 2x Serial Ports; Punch-out plates for 2x additional Serial Ports; 2x Punch-out plates for WiFi antenna.

Rear Panel: 12V power socket (connects to supplied 60W AC Adapter); 2x Punch-out plates for WiFi antenna; 2x USB 2.0; 2x Realtek RTL8111G Gigabit LAN; DVI-I port (VGA adapter included); 2x USB 3.0; 3.5mm Headphone-out port (Realtek ALC662 HD Audio); Punch-out plate for Serial Port.

Flexible Serial Port positioning: 4 Serial Ports are provided that can be distributed amongst 5 positions as required (1 in the front, 4 on the rear panel)

Power supply: Universal 100-240V External 60W AC Adapter with UK power cord connects to 12V power socket.

Wireless: The Jetway JBC375 WiFi is fitted with an internal Half Mini PCI Express Realtek RTL8723BE chipset 802.11 b/g/n WiFi card & External Antenna.

mSATA compatibility: The BayTrail chipset on this board is not currently compatible with all mSATA controllers - we have tested Intel, Kingston and Crucial drives successfully but others such as Sandisk may not be recognised.

Packing List: 1x JBC375; 1x AC Adapter; 1x Power Cable; 1x Installation CD; 1x Manual; 1x Screw Pack; 2x Din Rail Clips; 2x Metal Wall Mounts; 1x DVI-I to VGA Adapter.

Measurements: 180 x 142 x 48 mm / 7.1 x 5.6 x 1.89in (W x H x D); Volume: 1.23 litres.

Don't see what you want here? Send us an email with as much information as possible, and we'll try and get it for you.

Reckoner

Search tools:
Board Finder
Case Finder
Mini PC Finder

Cards accepted:
Secure Shopping:
