Intel Atom Mini-ITX Motherboards

Intel D2500HN Fanless Dual Core Atom Mini-ITX Board
ODM (Intel) D2500HN Fanless Dual Core Atom Mini-ITX Board
Intel D2550DC2 Fanless Dual Core Atom Mini-ITX Board
Fanless T1620 Thin-ITX Chassis & 60W PSU for DN2800MT

Jetway JNC9KSL-2500 Fanless Mini-ITX Board
Jetway JNC9KDL-2550 Fanless Dual LAN Mini-ITX Board
Jetway JNC9MGL-525 Dual LAN Mini-ITX Board with 6x Serial
Jetway JNF94-270 Long Life Fanless Atom Mini-ITX Board
Jetway JNF9C-2600 Long Life Thin-ITX Board with 12V DC In
Jetway JNF9C-2800 Long Life Thin-ITX Board with 12V DC In
Jetway JNF99-525 Fanless Dual LAN Expandable Mini-ITX Board

Intel D2500HN 1.86GHz Fanless Dual Core Atom Mini-ITX Board

Intel D2500HN Fanless Atom Mini-ITX Board
£55.00
  £66.00 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Intel D2500HN

You may also require:

2GB DDR3 1333 SODIMM for D2500HN
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

4GB DDR3 1333 SODIMM for D2500HN (if using one SODIMM, use SODIMM slot 1)
£32.00
  £38.40 inc. VAT
  IN STOCK (Checked 19:49 BST)

D2500HN Backplate for C1/C2-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Intel D2500HN 'Cedar Trail' motherboard with passively-cooled dual core Intel Atom D2500 processor running at 1.86GHz and Intel NM10 Express chipset. Integrated Intel GMA 3650 Video with VGA output; Up to 8GB of system memory (*see our note below regarding 64-bit video drivers); Intel 82574L Gigabit Ethernet Controller; 2+2 Channel Intel High Definition Audio; PCI connector.

This board can be considered a replacement/upgrade for the Intel D410MO and D425KT boards (though please consider the port and chipset differences).

Retail Unit complete with SATA cable, layout and back-panel stickers, product guide, Intel Express Installer driver and software DVD.

Rear Panel: VGA, Serial, Parallel, Combined PS/2 Keyboard or Mouse port, 4x USB 2.0, Gigabit Ethernet supporting LAN Wake with ACPI (Ping & Magic Packet), 3.5mm Line in, Line out & Mic in connectors.

Board Connectors: 24pin ATX Power connector (supports both 20pin and 24pin connectors), 2x DDR3 SODIMM Sockets; 2x SATA 3.0 Gb/s; 1x 32-bit PCI Slot; 2x 9-pin Front Panel USB Headers (supporting 4 additional USB 2.0 ports); Front Panel Header; Front Panel Audio header, S/PDIF out header, 1x Serial Port Header.

Suitable Cases: The D2500HN has a standard sized heatsink - all Mini-ITX cases with a power supply will fit. The board does not have an IDE port, so IDE devices cannot be connected (e.g. the CF reader on M200, M200-LCD, M300, M300-LCD).

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Recommended picoPSUs: All our picoPSUs will work with this board. If using one HDD, the picoPSU-80/90 and 60W/80W AC Adapter combination will be sufficient. A picoPSU with a 24pin ATX connector is not required.

Intel GMA 3600 Graphics: 400 MHz core frequency; High quality texture engine: DX9.3 and OpenGL 3.0 compliant, Hardware Pixel Shader 4.1, Vertex Shader Model 4.1; Video: Blu-ray 2.0, H.264 & VC1 hardware decoder, PAVP 1.1c, HDCP1.3.

*Support for 64-bit OS and 8GB Memory: This board operates in 64-bit mode and can address 8GB of memory. Intel's official support for this board is limited to 32-bit Windows (which can only address 3.5GB memory). No 64-bit video drivers are available, so 64-bit installations will have limited screen resolutions and no video acceleration. Screenshot of Linux operating in 64-bit mode here.

Drivers: Intel D2500HN product and driver pages.

Cooling: This board has no fan and will get quite warm under load. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and strongly suggest adding a fan if using a fanless case with this board (such as the M350 or Thin Client cases).

Memory Notes: The D2500HN supports up to 8GB DDR3 1333/1066 memory running at 1066MHz on 2x DDR3 SODIMMs. This is not compatible with DDR/DDR2 memory. Fully tested DDR3 SODIMMs are available here.

D2500HN 1.86GHz Fanless Dual Core Atom Mini-ITX Board (Intel ODM)

D2500HN Fanless Atom Mini-ITX Board (Intel ODM)
£55.00
  £66.00 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the D2500HN

You may also require:

2GB DDR3 1333 SODIMM for D2500HN
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

4GB DDR3 1333 SODIMM for D2500HN (if using one SODIMM, use SODIMM slot 1)
£32.00
  £38.40 inc. VAT
  IN STOCK (Checked 19:49 BST)

D2500HN Backplate for C1/C2-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



D2500HN 'Cedar Trail' motherboard with passively-cooled dual core Intel Atom D2500 processor running at 1.86GHz and Intel NM10 Express chipset. Integrated Intel GMA 3650 Video with VGA output; Up to 8GB of system memory (*see our note below regarding 64-bit video drivers); Intel 82574L Gigabit Ethernet Controller; 2+2 Channel Intel High Definition Audio; PCI connector.

Intel stopped producing motherboards under their own name in 2013. The same factory (ODM) continues to make these boards under licence from Intel. These boards are functionally and physically identical and with the same warranty, without the Intel logo.

This board can be considered a replacement/upgrade for the Intel D410MO and D425KT boards (though please consider the port and chipset differences).

Retail Unit complete with SATA cable, layout and back-panel stickers, product guide, Intel Express Installer driver and software DVD.

Rear Panel: VGA, Serial, Parallel, Combined PS/2 Keyboard or Mouse port, 4x USB 2.0, Gigabit Ethernet supporting LAN Wake with ACPI (Ping & Magic Packet), 3.5mm Line in, Line out & Mic in connectors.

Board Connectors: 24pin ATX Power connector (supports both 20pin and 24pin connectors), 2x DDR3 SODIMM Sockets; 2x SATA 3.0 Gb/s; 1x 32-bit PCI Slot; 2x 9-pin Front Panel USB Headers (supporting 4 additional USB 2.0 ports); Front Panel Header; Front Panel Audio header, S/PDIF out header, 1x Serial Port Header.

Suitable Cases: The D2500HN has a standard sized heatsink - all Mini-ITX cases with a power supply will fit. The board does not have an IDE port, so IDE devices cannot be connected (e.g. the CF reader on M200, M200-LCD, M300, M300-LCD).

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Recommended picoPSUs: All our picoPSUs will work with this board. If using one HDD, the picoPSU-80/90 and 60W/80W AC Adapter combination will be sufficient. A picoPSU with a 24pin ATX connector is not required.

Intel GMA 3600 Graphics: 400 MHz core frequency; High quality texture engine: DX9.3 and OpenGL 3.0 compliant, Hardware Pixel Shader 4.1, Vertex Shader Model 4.1; Video: Blu-ray 2.0, H.264 & VC1 hardware decoder, PAVP 1.1c, HDCP1.3.

*Support for 64-bit OS and 8GB Memory: This board operates in 64-bit mode and can address 8GB of memory. Intel's official support for this board is limited to 32-bit Windows (which can only address 3.5GB memory). No 64-bit video drivers are available, so 64-bit installations will have limited screen resolutions and no video acceleration. Screenshot of Linux operating in 64-bit mode here.

Downloads: Drivers and Documentation.

Cooling: This board has no fan and will get quite warm under load. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and strongly suggest adding a fan if using a fanless case with this board (such as the M350 or Thin Client cases).

Memory Notes: The D2500HN supports up to 8GB DDR3 1333/1066 memory running at 1066MHz on 2x DDR3 SODIMMs. This is not compatible with DDR/DDR2 memory. Fully tested DDR3 SODIMMs are available here.

Intel D2550DC2 1.86Hz Fanless Dual Core Atom Mini-ITX Board with HDMI, DVI-D and S/PDIF

Intel D2550DC2 Fanless Atom Mini-ITX Board
£59.00
  £70.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Intel D2550DC2

You may also require:

2GB DDR3 1333 SODIMM for D2550DC2
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

4GB DDR3 1333 SODIMM for D2550DC2 (if using one SODIMM, use SODIMM slot 1)
£32.00
  £38.40 inc. VAT
  IN STOCK (Checked 19:49 BST)

D2550DC2 Backplate for C1/C2-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Intel D2550DC2 'Cedar Trail' motherboard with passively-cooled dual core Intel Atom D2550 processor running at 1.86GHz and Intel NM10 Express chipset. Integrated Intel GMA 3650 Video with dual independent HDMI and DVI-D interfaces; Up to 8GB of system memory (*see our note below regarding 64-bit video drivers); Intel 82574L Gigabit Ethernet Controller; 5.1 Channel Intel High Definition Audio (Realtek ALC662 audio codec); PCI & Mini-PCI Express connectors.

This board can be considered a replacement/upgrade for the Intel D510MO and D525MW boards (though please consider the port and chipset differences).

Retail Unit complete with SATA cable, layout and back-panel stickers, product guide, Intel Express Installer driver and software DVD.

Rear Panel: S/PDIF optical audio out, HDMI, DVI-D (both outputs support up to 1920 x 1200 at 60 Hz), 4x USB 2.0, Gigabit Ethernet supporting LAN Wake with ACPI (Ping & Magic Packet), 3.5mm Line in, Line out & Mic in connectors.

Board Connectors: 24pin ATX Power connector (supports both 20pin and 24pin connectors), 2x DDR3 SODIMM Sockets; 2x SATA 3.0 Gb/s; 1x 32-bit PCI Slot; 1x Mini-PCI Express connector (support half and full length cards); 2x 9-pin Front Panel USB Headers (supporting 3 additional USB 2.0 ports); Front Panel Header; Front Panel Audio header, BIOS setup configuration jumper block.

Suitable Cases: The D2550DC2 has a standard sized heatsink - all Mini-ITX cases with a power supply will fit. The board does not have an IDE port, so IDE devices cannot be connected (e.g. the CF reader on M200, M200-LCD, M300, M300-LCD).

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Recommended picoPSUs: All our picoPSUs will work with this board. If using one HDD, the picoPSU-80/90 and 60W/80W AC Adapter combination will be sufficient. A picoPSU with a 24pin ATX connector is not required.

Intel GMA 3650 Graphics: 640 MHz core frequency; High quality texture engine: DX9.3 and OpenGL 3.0 compliant, Hardware Pixel Shader 4.1, Vertex Shader Model 4.1; Video: Blu-ray 2.0, H.264 & VC1 hardware decoder, PAVP 1.1c, HDCP1.3.

*Support for 64-bit OS and 8GB Memory: This board operates in 64-bit mode and can address 8GB of memory. Intel's official support for this board is limited to 32-bit Windows (which can only address 3.5GB memory). No 64-bit video drivers are available, so 64-bit installations will have limited screen resolutions and no video acceleration. Screenshot of Linux operating in 64-bit mode here.

Drivers: Intel D2550DC2 product and driver pages.

Cooling: This board has no fan and will get quite warm under load. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and strongly suggest adding a fan if using a fanless case with this board (such as the M350 or Thin Client cases).

Memory Notes: The D2550DC2 supports up to 8GB DDR3 1333/1066 memory running at 1066MHz on 2x DDR3 SODIMMs. This is not compatible with DDR/DDR2 memory. Fully tested DDR3 SODIMMs are available here.

Fanless T1620 Thin-ITX Chassis for DN2800MT Thin-ITX Board

T1620 Chassis with UK Power Cord
£55.00
  £66.00 inc. VAT
Lead time approx 1-2 weeks


More images of the T1620 Chassis

You may also require:

Intel DN2800MTE Fanless Thin-ITX Motherboard
£109.00
  £130.80 inc. VAT
Lead time approx 6-10 days

2GB DDR3 1333 SODIMM for DN2800MT
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

4GB DDR3 1333 SODIMM for DN2800MT (if using one SODIMM, use SODIMM slot 1)
£32.00
  £38.40 inc. VAT
  IN STOCK (Checked 19:49 BST)

Euro Power Cord for T1620
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 19:49 BST)

US Power Cord for T1620
£3.00
  £3.60 inc. VAT
  IN STOCK (Checked 19:49 BST)


Tiny 1.2 litre fanless case specifically designed *only* for the Intel DN2800MTE motherboard. Supplied with both VESA mounting bracket and vertical desk stand.

Construction: Heavy duty cast Aluminium construction with steel internal drive bracket.

Drive Bays: Supports 1x 2.5in HDD or SSD.

Front Panel: Power button; LED power or HDD indicator.

Power Supply included: 110-240V 60W External Universal AC Adapter; Internal power cable supplied with motherboard.

Desk/VESA Mounting: The case is supplied with both VESA adapter (75/100mm) and vertical desk stand. The VESA bracket can be used to attach the case to a wall.

Measurements: 38 x 178 x 178mm (1.5 x 7 x 7in); Volume: 1.2 litres.

Cooling: The T1620 is completely fanless. The case is supplied with a heat-transfer pad to assist cooling from the underside of the motherboard.

Supported boards: The T1620 *only* supports the Intel DN2800MTE motherboard.

Full case comparison, size and board compatibility chart

Jetway JNC9KSL-2500 Fanless Dual Core Atom Mini-ITX Board with VGA and HDMI

Jetway JNC9KSL-2500 Fanless Mini-ITX Board
£69.00
  £82.80 inc. VAT
  IN STOCK (Checked 19:49 BST)

More images of the Jetway JNC9KSL-2500

You may also require:

2GB DDR3 1333 SODIMM for JNC9KSL-2500
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

JNC9KSL Backplate for C1/C2/C3-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Good replacement board for Intel Atom boards such as D2500HN, D2550DC2, D2550MUD2.

Extremely versatile Jetway JNC9KSL-2500-LF Dual Core 1.86GHz Cedar Trail Intel Atom D2500 powered Mini-ITX motherboard with Fanless operation, Intel NM10 Chipset, Integrated Graphics and VIA VT1705 6-Channel Audio Codec. Supports up to 4GB of DDR3 SODIMM memory (*see our note below regarding 64-bit video drivers and 8GB support). Ports available include: 2x Realtek RTL8111EVL 10/100/1000 Base-T Gigabit LAN, 2x SATA 3Gb/s, 32-bit PCI slot.

Long Life: Product availability forecasted at least to End 2014, provisionally to End 2016.

Rear Panel Connectors: PS/2 Keyboard; PS/2 Mouse; 1x HDMI Port; 1x 10/100/1000 Realtek RTL8111EVL Gigabit LAN; 4x USB 2.0; 1x VGA Port; 3x 3.5mm Audio (Line-in; Mic-In; Stereo-Out).

Board connectors: 1x 24pin ATX Connector (works with 20pin or 24pin); 2x DDR3 SODIMM slots (2x 2GB max); 2x SATA 3Gb/s ports; 2x 9pin USB Connectors for 4x additional USB 2.0 Ports; 1x RS232 COM (Serial) Header; 1x Parallel Header; 1x 24bit single channel LVDS; 1x inverter; 1x Audio; 1x Front-Panel Connector; 1x CPU Fan; 1x Chassis Fan Connector.

Expansion: 1x 32-bit PCI slot.

Suitable cases & power supplies: The JNC9KSL-2500-LF has a standard sized heatsink and can be powered by 20pin and 24pin ATX power connectors. Compatible with all our picoPSUs and Mini-ITX cases, apart from the JC200 and JC203.

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Box contents: Motherboard, Manual, Driver CD, I/O shield, 2x SATA data cables, Serial port to pin header cable, 40mm CPU/Chipset Fan (optional but manufacturer recommended, does not add to the maximum height of the board).

Operating/Storage: 0~40 centigrade operating temperature. -20~85 centigrade storage temperature.

Cooling: This board will get quite warm under load and is provided with an optional 40mm fan. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and suggest adding the optional fan if using a fanless case with this board (such as the M350 or Thin Client cases).

*Support for 64-bit OS and 8GB Memory: This board operates in 32-bit mode only and officially only supports 4GB. Intel's support for this chipset is limited to 32-bit Windows (which can only address 3.5GB memory). However the board will address 8GB of memory (as 2x 4GB DDR3 SODIMMs), and 64-bit support is enabled in the BIOS. Please note though that as no 64-bit video drivers are available, 64-bit installations will use generic drivers meaning limited screen resolutions and no video acceleration.

Memory Notes: The JNC9KSL-2500 uses DDR3 SODIMM memory. This is not compatible with other types of memory. Fully tested DDR3 SODIMMs are available here. If using only one SODIMM, insert into SODIMM slot 2 (the lower slot).

Jetway JNC9KDL-2550 Fanless Dual Core Atom Mini-ITX Board with Dual LAN and VGA, HDMI

Jetway JNC9KDL-2550 Dual LAN Fanless Mini-ITX Board
£79.00
  £94.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Jetway JNC9KDL-2550

You may also require:

2GB DDR3 1333 SODIMM for JNC9KDL-2550
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

JNC9KDL Backplate for C1/C2-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Replaces the JNC9KDL-2700

Extremely versatile Jetway JNC9KDL-2550-LF Dual Core 1.86GHz Cedar Trail Intel Atom D2550 powered Mini-ITX motherboard with Fanless operation, Intel NM10 Chipset, Integrated Graphics and VIA VT1705 6-Channel Audio Codec. Supports up to 4GB of DDR3 SODIMM memory (*see our note below regarding 64-bit video drivers and 8GB support). Ports available include: 2x Realtek RTL8111EVL 10/100/1000 Base-T Gigabit LAN, 2x SATA 3Gb/s, 32-bit PCI slot.

Long Life: Product availability forecasted at least to End 2014, provisionally to End 2016.

Rear Panel Connectors: PS/2 Keyboard; PS/2 Mouse; 1x HDMI Port; 2x 10/100/1000 Realtek RTL8111EVL Gigabit LAN; 4x USB 2.0; 1x VGA Port; 3x 3.5mm Audio (Line-in; Mic-In; Stereo-Out).

Board connectors: 1x 24pin ATX Connector (works with 20pin or 24pin); 2x DDR3 SODIMM slots (2x 2GB max); 2x SATA 3Gb/s ports; 2x 9pin USB Connectors for 4x additional USB 2.0 Ports; 1x RS232 COM (Serial) Header; 1x Parallel Header; 1x 24bit single channel LVDS; 1x inverter; 1x Audio; 1x Front-Panel Connector; 1x CPU Fan; 1x Chassis Fan Connector.

Expansion: 1x 32-bit PCI slot.

Suitable cases & power supplies: The JNC9KDL-2550-LF has a standard sized heatsink and can be powered by 20pin and 24pin ATX power connectors. Compatible with all our picoPSUs and Mini-ITX cases, apart from the JC200 and JC203.

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Box contents: Motherboard, Manual, Driver CD, I/O shield, 2x SATA data cables, Serial port to pin header cable, 40mm CPU/Chipset Fan (optional but manufacturer recommended, does not add to the maximum height of the board).

Operating/Storage: 0~40 centigrade operating temperature. -20~85 centigrade storage temperature.

Cooling: This board will get quite warm under load and is provided with an optional 40mm fan. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and suggest adding the optional fan if using a fanless case with this board (such as the M350 or Thin Client cases).

*Support for 64-bit OS and 8GB Memory: This board operates in 32-bit mode only and officially only supports 4GB. Intel's support for this chipset is limited to 32-bit Windows (which can only address 3.5GB memory). However the board will address 8GB of memory (as 2x 4GB DDR3 SODIMMs), and 64-bit support is enabled in the BIOS. Please note though that as no 64-bit video drivers are available, 64-bit installations will use generic drivers meaning limited screen resolutions and no video acceleration.

Memory Notes: The JNC9KDL-2550 uses DDR3 SODIMM memory. This is not compatible with other types of memory. Fully tested DDR3 SODIMMs are available here. If using only one SODIMM, insert into SODIMM slot 2 (the lower slot).

Jetway JNC9MGL-525 Dual Core 1.8GHz Atom Mini-ITX Board with Dual LAN and up to 6x Serial Ports

Jetway JNC9MGL-525 Dual LAN Fanless Mini-ITX Board
£99.00
  £118.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Jetway JNC9MGL-525

You may also require:

2GB DDR3 1333 SODIMM for JNC9MGL-525
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

JNC9MGL Backplate for C1/C2-RACK Chassis
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Extremely versatile Jetway JNC9MGL-525-LF Dual Core 1.8GHz Intel Atom D525 powered Mini-ITX motherboard with Intel NM10 Chipset, Integrated Intel GMA 3150 Graphics and Realtek ALC662 6-Channel Audio Codec. Supports up to 4GB of DDR3 SODIMM memory. Ports available include: 2x Realtek RTL8111EVL 10/100/1000 Base-T Gigabit LAN, 2x SATA 3Gb/s, 32-bit PCI slot, Mini PCI Express socket.

Long Life: Product availability forecasted at least to Mid 2014.

Rear Panel Connectors: PS/2 Keyboard; PS/2 Mouse; 1x Serial (COM1); 1x Parallel; 1x VGA Port; 2x 10/100/1000 Realtek RTL8111EVL Gigabit LAN; 4x USB 2.0; 3x 3.5mm Audio (Line-in; Mic-In; Stereo-Out).

Board connectors: 1x 24pin ATX Connector (works with 20pin or 24pin); 2x DDR3 SODIMM slots (2x 2GB max); 2x SATA 3Gb/s ports; 1x 4pin and 1x 9pin USB Connectors for 3x additional USB 2.0 Ports total; 5x 9pin Serial Headers (COM2 supports RS232/485/422 and RS232 power, COM3-COM6 support RS232); 1x 4pin RS422/485 header (TX-RXCOM); 1x Power LED; 2x LAN Activity LED headers; 1x GPIO; 1x 18-bit single channel LVDS; 1x LVDS inverter; 1x S/PDIF Out; 1x Front Panel Audio; 1x Speaker; 1x Speaker header; 1x Front-Panel Connector; 1x 3pin CPU Fan; 2x 3pin System Fan Connectors.

Expansion: 1x 32-bit PCI slot; 1x Mini PCI Express socket.

Suitable cases & power supplies: The JNC9MGL-525-LF has a standard sized heatsink and can be powered by 20pin and 24pin ATX power connectors. Compatible with all our picoPSUs and Mini-ITX cases.

C1/C2/C3-RACK compatibility: Backplates are available designed for use with the C1-RACK, C2-RACK and C3-RACK (Dynatron K2 1U Side blower heatsink recommended).

Serial Ports: The JNC9MGL has 1x Serial Port on the back panel and pin headers for an additional 5x Serial Ports.

Box contents: Motherboard, Manual, Driver CD, I/O shield, 1x SATA data cable, 2x Serial port to pin header cables on removable PCI Backplates.

Operating/Storage: 0~40 centigrade operating temperature. -20~85 centigrade storage temperature.

Cooling: This board is provided with a 40mm fan on the heatsink.

Memory Notes: The JNC9MGL-525 uses DDR3 SODIMM memory. This is not compatible with other types of memory. Fully tested DDR3 SODIMMs are available here.

Jetway JNF94-270 Long Life Fanless Atom Mini-ITX Board

Jetway JNF94-270 Long Life Fanless Atom Mini-ITX Board
£99.00
  £118.80 inc. VAT
  IN STOCK (Checked 19:49 BST)

More images of the Jetway JNF94-270

You may also require:

2GB DDR2 800 SODIMM for JNF94-270*
£30.00
  £36.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Jetway JNF94-270 Fanless Atom motherboard. Fanless 1.6GHz Intel Atom N270 processor and integrated Intel GMA 950 Video. Intel 945GSE + ICH7M Chipset. Up to 2GB of DDR2 system memory on one SODIMM. Realtek RTL8111C Gigabit Ethernet and High Definition Realtek ALC662 Audio.

Long Life: Product availability forecasted at least to End 2014, provisionally to End 2015.

Power Consumption: Approximately 14W idle, 22W maximum power consumption.

Rear Panel Connectors: PS2 keyboard, VGA, DVI-D, Gigabit Ethernet, 4x USB 2.0 Ports, 2x Serial COM Ports (12V/5V selectable), Parallel Port, Line in, Line out & Mic in connectors.

Board Connectors: 1x 20-pin ATX power connector, 1x DDR2 SODIMM Socket, 1x 32-bit PCI, 2x SATA, 1x 40pin IDE, 1x RS232 COM port (COM3, 12V/5V selectable), 1x RS232/RS485/RS422 COM port (COM4, 12V/5V selectable), 1x 8bit GPIO, 1x 18bit dual channel LVDS, 2x Front Panel USB Header (for 4x USB 2.0 ports), 1x HDTV output, 2x DC Fan Headers, 1x CPU Smart Fan Header, Front Panel Header.

Case compatibility. Suitable cases: Most Mini-ITX cases including Jou Jye 528i, Noah 3988, Chenbro NAS, Venus 669, Nexus Psile, M200/M300/M350 (with any picoPSU), C1-RACK, Travla C146,147,159 (with universal backplate), Thin Client, Travla C158 (CD supported), Travla C137 (CD supported), Compact Wall Mount Case (with HDD). Other cases supporting standard height heatsinks.

Operating temperature: Operates within 0~60 centigrade (Storage within -20~+85 centigrade).

Box contents: Motherboard, 2x SATA cables, Product Manual, 3 way IDE cable, I/O Shield, Driver and Software CD, HDTV pin header cable.

*Note: The JNF94 supports up to 2GB DDR2 memory on a DDR2 SODIMM, running at 533MHz.This is not compatible with DDR or standard DIMM memory. Fully tested DDR2 SODIMMs are available here.

Jetway JNF9C-2600 Long Life Fanless 1.6GHz Atom Thin-ITX Board with 12V DC Input and CFAST

Jetway JNF9C-2600 Fanless 1.6GHz Atom Thin-ITX Board with 12V DC Input
£99.00
  £118.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Jetway JNF9C-2600

You may also require:

2GB DDR3 1333 SODIMM for JNF9C-2600 (1 stick supported)
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

60W AC Adapter for JNF9C-2600 (UK plug)
£19.00
  £22.80 inc. VAT
  IN STOCK (Checked 19:49 BST)

80W AC Adapter for JNF9C-2600 (UK plug)
£25.00
  £30.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

More 12V AC Adapters



Long-life board with 5 year availability and ultra-low profile form factor (20mm high). Fanless 1.6GHz Intel Atom N2600 processor and integrated PowerVR SGX 545 (GMA 3600@400MHz) Graphics. Intel NM10 Chipset. Up to 2GB of DDR3 system memory on one SODIMM. Realtek RTL8111EVL Gigabit Ethernet and High Definition Realtek ALC662 Audio. CFast Embedded Storage Socket onboard.

Long Life: Product availability forecasted at least to Mid 2016, Provisionally to End 2016.

Rear Panel Connectors: 12V DC Input, HDMI, RS232 Serial, 3x USB 2.0 Ports, Gigabit Ethernet, 1x 3.5mm Audio.

Board Connectors: CFast Embedded Storage Socket; 4pin Power out (cable provided); 1x DDR3 SODIMM Socket; 1x 32-bit PCI; 1x Mini PCI-Express (Full and Half Length, no adapter required); 2x SATA 3Gb/s; 1x SATA 6Gb/s; 2x RS232 Serial header. 1x RS232/422/485 Serial header; 4x USB 2.0 headers on 2x 9pin connectors; 1x Parallel; 1x GPIO; 1x 32pin 24bit dual channel LVDS1 header/inverter (CHRONTEL CH7511B chipset up to 1920 x 1200); 1x 32pin 18bit single channel LVDS2 header/inverter (PowerVR SGX 545 chipset); 1x VGA header; 3x Fan Headers; Front Panel Header; 9-pin Audio; Keyboard/Mouse header.

Important! This board has a DC Power input and is not designed for use with a standard ATX PSU: The JNF9C-2600 requires a 12V AC Adapter to power the board at the rear and feeds power to up to 3 other SATA devices through an on-board 4pin power output connector. There is an alternate 12V input on a 4pin Molex P4-type connector which can also be used (though not at the same time as the rear input).We sell several enclosures without power supplies, or you can bypass the PSU on any other compatible Mini-ITX case. 80W is enough to power 3x HDDs or Slimline Optical Drives, but we *do not* recommend powering a full size optical drive.

Powering devices: An internal 4pin power output cable is provided. Other devices (including SATA slimline optical drives and CF cards) may require additional cables. Please email before ordering. Don't forget you can install Linux and Windows 7 from a USB key very easily!

Suitable cases (without PSU): The following enclosures come without an internal PSU and are compatible with the JNF9C-2600: M350 and M5X.

Suitable cases (with PSU): All Mini-ITX Chassis can be used with the JNF9C-2600 if their PSU is bypassed and a 12V external AC Adapter is used (60W minimum).

Box contents: Motherboard, SATA cables, Product Manual, Short depth Thin-ITX and Standard I/O Shields, Driver and Software CD, Serial Cable.

Note: The JNF9C-2600 supports up to 2GB DDR3 memory on a DDR3 SODIMM. This is not compatible with DDR or standard DIMM memory. Fully tested DDR3 SODIMMs are available here.

Jetway JNF9C-2800 Long Life Fanless 1.86GHz Atom Thin-ITX Board with 12V DC Input, 4GB Support and CFAST

Jetway JNF9C-2800 Fanless 1.86GHz Atom Thin-ITX Board with 12V DC Input
£109.00
  £130.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Jetway JNF9C-2800

You may also require:

2GB DDR3 1333 SODIMM for JNF9C-2800 (2 sticks supported)
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

60W AC Adapter for JNF9C-2800 (UK plug)
£19.00
  £22.80 inc. VAT
  IN STOCK (Checked 19:49 BST)

80W AC Adapter for JNF9C-2800 (UK plug)
£25.00
  £30.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

More 12V AC Adapters



Long-life board with 5 year availability and ultra-low profile form factor (20mm high). Fanless 1.86GHz Intel Atom N2800 processor and integrated PowerVR SGX 545 (GMA 3650@640MHz) Graphics. Intel NM10 Chipset. Up to 4GB of DDR3 system memory on 2x 2GB SODIMMs. Realtek RTL8111EVL Gigabit Ethernet and High Definition Realtek ALC662 Audio. CFast Embedded Storage Socket onboard.

Long Life: Product availability forecasted at least to Mid 2016, Provisionally to End 2016.

Rear Panel Connectors: 12V DC Input, HDMI, RS232 Serial, 3x USB 2.0 Ports, Gigabit Ethernet, 1x 3.5mm Audio.

Board Connectors: CFast Embedded Storage Socket; 4pin Power out (cable provided); 1x DDR3 SODIMM Socket; 1x 32-bit PCI; 1x Mini PCI-Express (Full and Half Length, no adapter required); 2x SATA 3Gb/s; 1x SATA 6Gb/s; 2x RS232 Serial header. 1x RS232/422/485 Serial header; 4x USB 2.0 headers on 2x 9pin connectors; 1x Parallel; 1x GPIO; 1x 32pin 24bit dual channel LVDS1 header/inverter (CHRONTEL CH7511B chipset up to 1920 x 1200); 1x 32pin 18bit single channel LVDS2 header/inverter (PowerVR SGX 545 chipset); 1x VGA header; 3x Fan Headers; Front Panel Header; 9-pin Audio; Keyboard/Mouse header.

Important! This board has a DC Power input and is not designed for use with a standard ATX PSU: The JNF9C-2800 requires a 12V AC Adapter to power the board at the rear and feeds power to up to 3 other SATA devices through an on-board 4pin power output connector. There is an alternate 12V input on a 4pin Molex P4-type connector which can also be used (though not at the same time as the rear input). We sell several enclosures without power supplies, or you can bypass the PSU on any other compatible Mini-ITX case. 80W is enough to power 3x HDDs or Slimline Optical Drives, but we *do not* recommend powering a full size optical drive.

Powering devices: An internal 4pin power output cable is provided. Other devices (including SATA slimline optical drives and CF cards) may require additional cables. Please email before ordering. Don't forget you can install Linux and Windows 7 from a USB key very easily!

Suitable cases (without PSU): The following enclosures come without an internal PSU and are compatible with the JNF9C-2800: M350 and M5X.

Suitable cases (with PSU): All Mini-ITX Chassis can be used with the JNF9C-2800 if their PSU is bypassed and a 12V external AC Adapter is used (60W minimum).

Box contents: Motherboard, SATA cables, Product Manual, Short depth Thin-ITX and Standard I/O Shields, Driver and Software CD, Serial Cable.

Note: The JNF9C-2800 supports up to 4GB DDR3 memory on 2x 2GB DDR3 SODIMMs (our pictures are of the JNC9C-2600, which has 1 slot). DDR3 is not compatible with DDR or standard DIMM memory. Fully tested DDR3 SODIMMs are available here.

Jetway JNF99-525 Long Life Fanless Dual Core Atom Mini-ITX Board with Dual LAN, 6x SATA and Daughterboard Expansion

Jetway JNF99 Dual LAN Fanless Expandable Mini-ITX Board
£139.00
  £166.80 inc. VAT
  IN STOCK (Checked 19:49 BST)


More images of the Jetway JNF99-525

You may also require:

2GB DDR3 1333 SODIMM for JNF99-525
£20.00
  £24.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

3x Gigabit LAN Daughterboard Module
£29.00
  £34.80 inc. VAT
  IN STOCK (Checked 19:49 BST)

3x Gigabit LAN Daughterboard Module (Intel 82541PI chipset)
£45.00
  £54.00 inc. VAT
  IN STOCK (Checked 19:49 BST)

JNF99 Backplate for C1/C2-RACK
£10.00
  £12.00 inc. VAT
  IN STOCK (Checked 19:49 BST)



Extremely versatile Jetway JNF99-525-LF Dual Core 1.8GHz 64-bit Intel Atom D525 powered Mini-ITX motherboard with Fanless operation, Jetway Daughterboard Expansion, Intel ICH9R Chipset, Integrated Graphics and VIA VT1705 6-Channel Audio Codec. Supports up to 4GB of DDR3 1066/1333MHz SODIMM memory. Ports available include: 2x Intel 82574L 10/100/1000 Base-T Gigabit LAN, 6x SATA 3Gb/s (supporting RAID 0, 1, 5, 10 & JBOD), USB 3.0, PCI and Mini-PCI Express.

Long Life: Product availability forecasted at least to End 2014, provisionally to End 2016.

Jetway JNF99 Mini-ITX motherboards have a unique expansion module slot to add additional ports and functionality - up to 3x Gigabit LAN, 4x Serial Ports and more are all available.

Expandable with a Jetway Daughterboard Module

Rear Panel Connectors: 1x Combined PS/2 Keyboard or Mouse; 2x USB 3.0; 1x VGA Port; 1x Serial COM Port; 2x 10/100/1000 Intel 82574L Gigabit LAN; 3x USB 2.0 Ports; 3x 3.5mm Audio (Line-in; Mic-In; Stereo-Out).

Board connectors: 1x 24pin ATX Connector (works with 20pin or 24pin); 2x DDR3 SODIMM slots (2x 2GB max); 6x SATA 3Gb/s ports (with RAID 0, 1, 5, 10 & JBOD support); 3x 9pin USB Connectors for 6x additional USB 2.0 Ports; 1x RS422/RS485 COM (Serial) Header; 1x Parallel Header; 1x 32bit LVDS; 1x GPIO; 1x Audio; 1x Front-Panel Connector; 1x CPU Smart Fan; 1x DC Fan Connector.

Expansion: 1x 32-bit PCI slot; 1x Mini-PCI Express Slot; 1x 120pin Jetway Embedded PCI Daughterboard Expansion Slot.

Suitable cases & power supplies: The JNF99 has a standard sized heatsink and can be powered by 20pin and 24pin ATX power connectors. Compatible with all our picoPSUs and Mini-ITX cases.

Box contents: Motherboard, Manual, Driver CD, I/O shield, 6x SATA data cables, Serial port to pin header cable.

Operating/Storage: 0~60 centigrade operating temperature. -20~85 centigrade storage temperature.

Cooling: This board has no fan and will get quite warm under load. Successful motherboard and case cooling is a combination of external environment, internal airflow, heatsink size, chassis design and workload. We recommend always connecting any existing case fans, and strongly suggest adding a fan if using a fanless case with this board (such as the M350 or Thin Client cases).

Memory Note: The JNF99 uses DDR3 SODIMM memory. This is not compatible with other types of memory. Fully tested DDR3 SODIMMs are available here.

Don't see what you want here? Send us an email with as much information as possible, and we'll try and get it for you.


Reckoner

Cards accepted:
Secure Shopping:

Contact Us

Store: +44 (0) 845 475 8 475

Store enquiries: store@mini-itx.com

Other enquiries: feedback@mini-itx.com

Visit the Store

Click here to enter the online store

Social

Follow us on Twitter!

Join our Mailing List

Copyright: All content on this site is Copyright © 2002-2014 Mini-ITX.com and respective owners, all rights reserved.
